General Maintenance
6.26
Front Panel - FX/FXS
The right front panel must be removed to gain access to the 12 volt
fuse center.
Removing the body panel
1. Remove seat.
2. Remove 6 fasteners securing the body panel to the frame.
3. Remove body panel.
Installing the body panel
1. Installation of the front panel is the reverse of the removal
procedure.
Note: When installing the body panel, make sure that no
cables/wires are trapped between the frame and panel before
tightening the fasteners.
