Installation & Operation • 9
INSTALLATION & OPERATION
ITEM
SHELF
DESCRIPTION
MAXIMUM LOAD
PER SHELF
1 22" and 24" deep 250 lbs.
2 Bakery or Meat Brackets
At 0° 250 lbs.
At 5° 250 lbs.
At 10° 150 lbs.
At 15° 100 lbs.
3 Ice Shelves 500 lbs.
Heavy duty shelves are available and are labeled as such.
Light Switch
The light switch is located on the ceiling on the right-hand side of the display case.
Case Thermometer
The cases are shipped with 2 thermometers. One thermometer is factory-mounted in the discharge air stream. The second thermometer is
shipped loose and should be installed in the warmest product location. Specic instructions are packaged with the shipped loose thermometer.
