Revision Date – 15/07/2020 page 44
Remove the wires connected to the AC Rectifier.
These screws are located to the left as shown.
Disconnect and remove the wires connected to
the AC power socket.
Disconnect and remove the wires connected to
the Main PCB.
The AC Rectifier can now be removed from the
fridge.
To refit the AC Rectifier, reverse the process as
described in this section.
Once installed and secured safely, ensure the AC
Rectifier is functioning correctly as per Section
8.2.
