Zero ARB Service Manual

Revision Date – 15/07/2020 page 34
9.3 Front Cover – Replace
To remove front cover
Disconnect all power leads from the back of the
fridge.
Remove the two rear columns secured to the front
cover as described in Section 9.2.
Remove the side screws from the front cover.
There are three screws on each side of the front
cover.
Remove the base screws from the front cover.
There are twelve (12) screws to remove.
The rear cover can be flipped back to access
various systems of the fridge.
If the front cover does not need replacing, you
may not need to continue through the remaining
steps.

Zero ARB Specifications

General

Brand	Zero
Model	ARB
Category	Freezer
Language	English
