DMX Input JesterML Operating Manual
73-406-00 Issue 3.0 43 of 85
bottom bank of faders is paged by the Page B button, and
controls submasters.
In this mode, the +DMXin indication on the monitor will be
replaced with +WingNN, where NN is the Wing Width.
Subs Only In this mode, the first 24 levels from the DMX Input are used to
control submasters in Run Mode. In Program Mode, Memories
and submasters are not recorded with additional LTP channels
grabbed from the DMX input, to avoid wasting storage space. In
this mode, the +DMXin indication on the monitor will be replaced
with +SMWing.
Wing modes - Chans+Subs & Subs Only
Levels received from the DMX Input are HTP mixed with the local faders (if present).
Channel levels received from the wing will be treated simply as fader positions, the
JesterML does not attempt to detect flash button presses from the wing. Thus the
flash buttons on the wing can not be used for the following:
• Soloing (Preset Mode and Run Mode).
• Submaster selection (Program Mode and Run Mode). Press PAGE B to use
the Multi-Function-Keys for this.
• Channel selection (DMX Patch menu in Setup) – the cursor buttons can
instead be used to select channels.
• Name / number entry – the Multi-Function-Keys, Cursor Buttons or USB
Keyboard can be used for this.
DMX Input Tutorial
The example given below shows how to set up a Jester24/48 with a JesterML.
Connect Up
Connect up as shown below:
Jester24/48
JesterML
To Next Page
