Zest ZQ280S2D2 - F6 Group: Analog Input and Output Parameters

Function
code
Name Description
Setting
range
Factory
default
F6.00
Lower limit voltage
of AVI input
0.0%
F6.01
Upper limit voltage
of AVI input
100.0%
F6.02
Setting corresponding to AVI
lower limit
0.0%
F6.03
Setting corresponding to AVI
upper limit
100.0%
F6.04
Lower limit current
of ACI input
0.0%
F6.05
Upper limit current
of ACI input
100.0%
F6.06
Setting corresponding to ACI
lower limit
0.0%
F6.07
Setting corresponding to ACI
lower limit
100.0%
F6.08
Constant for filtering
time of analog input
signal
This parameter is used for filtering the input
signals of AVI, ACI and panel
potentiometer to eliminate the effect of
interference.
0.1-5.0s 0.1s
F6.09 Error limit of analog input
When analog input signal shows frequent
fluctuation around the set point, set F6.09 to
restrain the frequency
fluctuation caused by this fluctuation.
0.0-100.0% 0.0
F6.10 A01 output selection
0：Output frequency, 0-Max frequency
1：Given frequency, 0-Max frequency
2：Output current, 0-2 times rated current
3：Output voltage, 0-2 times rated voltage
4：AVI, 0-10V
5：ACI, 0-20mA
0-5 0.0
F6.11 AO function lower limit 0.0
F6.12 AO function upper limit 100.0%
F6.13 AO output lower limit 0.0
F6.14 AO output upper limit 100.0%
F7.00 Multi-speed frequency 1
Set multi-speed 1 frequency
5.0Hz
F7.01 Multi-speed frequency 2
Set multi-speed 1 frequency
10.0Hz
F7.02 Multi-speed frequency 3
Set multi-speed 1 frequency
15.0Hz
F7.03 Multi-speed frequency 4
Set multi-speed 1 frequency
20.0Hz
F7.04 Multi-speed frequency 5
Set multi-speed 1 frequency
25.0Hz
F7.05 Multi-speed frequency 6
Set multi-speed 1 frequency
37.5.0Hz
F7.06 Multi-speed frequency 7
Set multi-speed 1 frequency
50.0Hz
F7.07 PLC run mode selections
0：Stop after single cycle
1：Continuous cycles
2： Keep final value after single cycle
0-2 0
F7.08 Stop save mode
0：No save 1：Save
0-1 0
F7.09 Power down save mode
0：No save 1：Save
0-1 0
F7.10 1st step running time T1
Set multi-speed 1 running time
10.0s
F7.11 2nd step running time T2
Set multi-speed 2 running time
10.0s
F7.12 3rd step running time T3
Set multi-speed 3 running time
10.0s
F7.13 4th step running time T4
Set multi-speed 4 running time
10.0s
F7.14 5th step running time T5
Set multi-speed 5 running time
10.0s
F7.15 6th step running time T6
Set multi-speed 6 running time
10.0s
F7.16 7th step running time T7
Set multi-speed 7 running time
10.0s
lower limit
frquecy
-
upper limit
frequency
0.0-100.0%
0.0-100.0%
0.0-999.9s
F7 group:PLC、Multi-speed Parameters
Set the upper and lower limit of the function
selected by AO
Set AO output upper and lower limits
Set the setting corresponding to the ACI upper
and lower limits, which corresponds to the
percentage of the upper limit frequency [F0.09]
-100.0%-
100.0%
F6 group: Analog Input and Output Parameters
Set AVI upper and lower limit voltage
0.00-100.0%
Set the setting corresponding to the AVI upper
and lower limits, which corresponds to the
percentage of the upper limit frequency [F0.09]
-100.0%-
100.0%
Set ACI upper and lower limit current
0.00-100.0%
14
