Function
code
Name Description
Setting
range
Factory
default
F7.17 T1 run mode selections 0
F7.18 T2 run mode selections 0
F7.19 T3 run mode selections 0
F7.20 T4 run mode selections 0
F7.21 T5 run mode selections 0
F7.22 T6 run mode selections 0
F7.23 T7 run mode selections 0
F7.24
Current running
multi-speed(Reserve)
F7.25
Current running time
(Reserve)
F8.00 PID feedback trait selection
0：Positive trait 1：Negative trait
0-1 0
F8.01 PID give signal source
0：Keyboard number given
1：Keyboard Potentiometer given
2：AVI
3：ACI
0-3 0
F8.02 PID feedback signal source
0：AVI 1：ACI
0-1 0
F8.03 Keyboard number PID given
The given value when the PID given source is
Keyboard number setting
PID range
lower limit
-
PID range
upper limit
0.5
F8.04
PID instruction acceleration and
deceleration time
0.0-100.0s 0.0
F8.05 PID control deviation limit 0.0-100.0% 0.0
F8.06
PID control deviation limit
keeping time
0.0-6000.0s 0.0
F8.07 PID deviatiom upper limit 0.0-100.0% 100.0
F8.08 PID deviatiom lower limit 0.0-100.0% 0.0
F8.09 Proportion gain 0.00-600.00 25.00
F8.10 Integral time
0：No
Integral time
0.0-100.0s
1.0
F8.11 Differential coefficient
0：No
Differential
coefficient
0.00-10.00s
0.00
F8.12 PID output upper limit 0.0-100.0% 100.0
F8.13 PID output lower limit 0.0-100.0% 0.0
F8.14 PID output filter time 0.00-10.00 0.00
F8.15 Feedback fault action selection
0：Run at the upper limit frequency
1：Run at the lower frequency limit
2：Run according to the digital set frequency
3：Decelerate to stop
4：Free stop
0-4 2
F8.16
PID feedback loss detection
value
0.0-100.0% 0.0
F8.17 PID feedback loss detection time 0.0-100.0s 1.0
F8.18
PID feedback over-limit detection
value
0.0-100.0% 100.0
F8.19
PID feedback over-limit detection
time
0.0-100.0s 1.0
F8 group: PID Control, MPPT And PV Pump Parameters
0：Forward, Select acceleration time 1
1：Forward, Select acceleration time 2
2：Reverse, Select acceleration time 1
3：Reverse, Select acceleration time 2
0-3
15
