MAINTENANCE SCHEDULE
Table 5
MAINTENANCE
SECTION
5
An alignment error could cause irreversible damage to the transmission, together with noise,
vibration and damage to the hull seal systems.
ZF Padova S.p.A. is relieved of all liability for breakage under warranty.
When installing the transmission, make sure enough space is left for maintenance access: i.e. chan-
ging the oil filter, dipstick access.
Check that the oil drain plug is easily accessible.
PERMITTED INSTALLATION ANGLES
FOR SAILING [
O
]
(Referred to perpendicular and
longitudinal axes of input shaft
in relation to horizontal plane)
Longitudinal static
Pitch
Roll
– 5
÷ + 10
– 10 ÷ + 25 – 15 ÷ + 15
Table 4
Check for oil leaks
Check oil level
Tighten all external threaded fasteners
Adjust shift control linkage
Suction filter
Clean transmission externally
Lubricate external moving parts
Oil change
Replace Oil Filter
Inspect flexible coupling
Resilient mounts
Check instruments and indicators
Replace zinc anodes
Oil cooler
Annually / 500 hours
Six-monthly / 250 hours
Daily
After the first 50 hours
operation
MAINTENANCE OPERATIONS
