Zhiyun SMOOTH 4 User Manual

11
The Use of Stabilizer
Quick Switch to Standby Mode
While stabilizer is powered on, put the horizontal
arm down by hand, the horizontal arm is
automatically locked with Fixing Buckle and the
stabilizer enters standby mode. Before turning
on or waking up stabilizer, manually separates
stabilizer from the Fixing Buckle.
Moving horizontal arm to horizontal position to
wake up stabilizer.

Zhiyun SMOOTH 4 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Product color	Black
Maximum weight capacity	0.21 kg
Mechanical roll range	0 - 240 °
Charging time	3.5 h
Operating time	12 h
Battery voltage	7.4 V
Battery capacity	2000 mAh
Built-in battery	Yes
Operating temperature (T-T)	-10 - 45 °C
Package depth	374 mm
Package width	157 mm
Package height	70 mm
Package weight	888 g
Cables included	USB

Weight and Dimensions

Depth	105 mm
Width	123 mm
Height	328 mm
Weight	547 g
