Zhiyun SMOOTH 4 User Manual

12
To charge the phone, you should use the cable
with one end as Micro USB port and another as
charging port for phone, connect stabilizer and
phone, then stabilizer starts charging the phone.
Charging Phone
Manual Reposition
In pan following mode or locking mode, you can
rotate phone to the angle that you want, then
release it and phone angle can be fixed. In pan
following mode, you can manually adjust tilt angle
and in locking mode you can manually adjust tilt
axis and pan axis angle.
The Use of Stabilizer
DO NOT charge
via the Micro USB
port on tilt axis,
otherwise it may
lead to a short or
burn in the circuit
board.

Zhiyun SMOOTH 4 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Product color	Black
Maximum weight capacity	0.21 kg
Mechanical roll range	0 - 240 °
Charging time	3.5 h
Operating time	12 h
Battery voltage	7.4 V
Battery capacity	2000 mAh
Built-in battery	Yes
Operating temperature (T-T)	-10 - 45 °C
Package depth	374 mm
Package width	157 mm
Package height	70 mm
Package weight	888 g
Cables included	USB

Weight and Dimensions

Depth	105 mm
Width	123 mm
Height	328 mm
Weight	547 g
