3 - 6 MC1000 with Windows CE 4.2 User Guide
Battery Charging
The Four Slot USB cradle can charge up to four mobile computers simultaneously. The Li-ion battery charges in
approximately four hours. To charge the mobile computer:
1. Connect the Four Slot USB cradle to a power source.
2. Firmly press the mobile computer into the mobile computer slot.
3. The mobile computer’s Charge LED indicates the mobile computer battery charging status.
4. When charging is completed, hold the cradle with one hand and lift the mobile computer out of the cradle with
the other hand.
Cables
This section describes how to set up and use the cables. The cables:
•
provide the mobile computer’s operating power and battery charging power when used with the approved
power supply.
•
provide serial connection through the serial pass-through port for communication with a serial device, such
as a host computer. For communication setup procedures, refer to the MC1000 Integrator Guide.
•
provide USB connection through the USB pass-through port for communication with a USB device, such as a
host computer. For communication setup procedures, refer to the MC1000 Integrator Guide.
•
provide printing capabilities to an approved printer.
Cable Connection
1. Slide the bottom of the mobile computer into the cable cup and gently press it down until it is firmly seated in
the cable cup.
NOTE Re-chargeable AAA batteries do not charge in the mobile computer when the mobile computer is placed
in the Four Slot USB cradle.
To charge the battery for your mobile device, battery and charger temperatures must be between +32° F
and +104° F (0° C to +40° C).
UConnect software must be loaded onto the mobile computer for proper ActiveSync operation. Refer to
the MC1000 with Windows CE 4.2 Integrator Guide for installing UConnect onto the mobile computer.
NOTE Use only a approved power supply output rated 5.4 VDC and minimum 3 A. The power supply is certified
to EN60950 with SELV outputs. Use of alternative power supply will invalidate any approval given to this
device and may be dangerous.
HINWEIS Benutzen Sie nur eine genehmigt in den Ausgabe: 5.4 VDC und minimum 3A. Die Stromversorgung ist
bescheinigt nach EN60950 mit SELV Ausgaben. Bei Verwendung eines anderen Netzteils werden alle
für das Gerät gewährten Genehmigungen außer Kraft gesetzt, und der Betrieb kann gefährlich sein.
