Zimmer Cryo 7 - Page 3

Figures
Rear of the device
Fig. 3
9
RS232 connection port for data communication with medical technology devices
10
Connection port for USB
11
Handle
12
Air filter
13
Ventilation slits
14
Base
15
Castors with locking device
16
Locking lever
17
Connection for power cable
18
Mains switch
19
Air outlet with magnetic connection and treatment tube connection
20
Connection port for spring arm
18
17
19
20
16
