ZIMO MX645 - New Family MX634

Page 4 Non-Sound Decoder MX618 - MX638 and Sound Decoder MX640 - MX659
SOUND DECODERS:
MX647, MX646
Production ended in 2012 and 2015 respectively;
replaced by MX649.
20 x 11 x 4mm SOUND - 0.8A - 6 Fu-Outputs - 2 Servos - SUSI
MX648
Family
Subminiature-Sound-Decoder, 1 Watt Audio on 8 Ohm speaker
TYPICAL APPLICATION: Vehicles in N, TT, HOe, HOm and in HO vehicles with
limited space.
MX648 plug configurations:
MX648
11 highly flexible wires for pick-up, motor, 4 Fu-Outputs, speaker, solder pads
for 2 more Fu-Outputs as logic level outputs, servos and SUSI.
MX648R
MX648 with 8-pin plug as per NEM652 on 70mm wires.
MX648F
MX648 with 6-pin plug as per NEM651 on 70mm wires.
MX648P16
MX648 with 16-pin PluX connector (male), 4 function outputs through plug.
23 x 9 x 4mm SOUND - 1.0A - 4 Fu-Outputs - 2 Servos - SUSI
MX649
Family
Miniature-Sound-Decoder, 1 Watt Audio on 8 Ohm speaker
TYPICAL APPLICATION: Vehicles in N, TT, HOe, HOm and in HO vehicles with
limited space.
MX649 plug configurations:
MX649
11 highly flexible wires for pick-up, motor, 4 Fu-Outputs, speaker, 2 solder pads
for logic level outputs, servos and SUSI.
MX649N
MX649 with 6-pin plug as per NEM651 mounted on circuit board and two addi-
tional speaker wires.
MX649L
MX649 with 90
o
6-pin plug as per NEM651 mounted on circuit board and two
additional speaker wires.
MX649R
MX649 with 8-pin plug as per NEM652 on 70mm wires.
MX649F
MX649 with 6-pin plug as per NEM651 on 70mm wires.
MX647L
Produced only during Oct. 2010, before the MX646 became available.
MX640, MX642, MX643
Production ended in 2011;
replaced by MX645 and MX644.
30 x 15 x 4mm SOUND - 1.2A - 8 - 10 Fu-Outputs - 2 Servos - SUSI
MX645
and
MX644
Family
MX645 and MX644 replace MX640, MX642 MX643…
H0-Sound-Decoder with 10 (MX645) or 6 (MX644) function outputs, 3 Watt
audio on 4 Ohm speaker (or 2 x 8 Ohm), with energy storage circuitry.
TYPICAL APPLICATION: HO, O and similar gauges.
MX645/MX644 plug configurations: ATTENTION: OEM installed decoder sometimes have less function outputs.
MX645
13 highly flexible wires (120mm) for pick-up, motor, 4 Fu-Outputs, speaker, ener-
gy storage circuitry, solder pads for additional 6 Fu-Outputs, servos and SUSI.
MX645R
MX645 with 8-pin plug as per NEM652 on 70mm wires.
MX645F
MX645 with 6-pin plug as per NEM651 on 70mm wires.
MX645P16
MX645 with 16-pin PluX connector, 4 Fu-Outputs through plug.
MX645P22
MX644D
MX644C
MX645 with 22-pin PluX connector, 9 Fu-Outputs (+ extra output outside plug).
Similar to MX645 but with 21-pin “MTC“ plug mounted on circuit board.
Similar to MX645 but for Märklin-, Trix etc.; with FO3, FO4 logic level only.
25 x 10.5 x 4mm SOUND - 0.8A - 4 Fu-Outputs + 2 Logic level - SUSI
MX658N18
Next18 Sound-Decoder, (“Rail community” standard RCN-118)
20 x 9,5 x 4 mm SOUND - 0,8 A - 4 Fu-Ausgänge + 2 Logikpegel - SUSI - DCC, MM, DC, AC
MX659N18
Next18 - Sound-Decoder („Railcommunity“ Norm RCN-118)
