ZINCKER VAULTA K1 - Install the Exterior Assembly; Prepare door and exterior assembly; Mount exterior assembly

Make sure the door
is open.
Make sure the keyhole is
in vertical position.
Insert the Exterior Assembly onto the door with the rod bolts going through the round holes on the
latch, and the square spindle and the control wire going through the square-shaped (center) hole.
Forcing the control wire
into any other place than
specified above will
damage the connector,
making the door knob
unusable.
The “UP” mark on the
spindle should face upward
Install the Exterior Assembly
3
1
2
4
12
3
UP
