Make sure this side
points downward.
Install the Interior Assembly
4
Remove the screw on top and then pull out the cover.
Install interior knob onto the door with the rod bolts
going through the round holes on the latch, and the
square spindle and the control wire going through
the square-shaped (center) hole.
Secure both exterior and interior knobs to the door
using the
2-1/3” (60mm)
or
1-1/2” (40mm)
screws.
Tighten them with a Phillips Screwdriver (DO NOT
over-tighten).
Plug the control wire male plug to the female
socket located on the battery compartment.
Install the batteries into the compartment.
Press and hold the reset button until you
hear a long beep.
1 4
5
6
Install and then secure the cover with the screw.
7
2
3
13
Reset Button
To Next Page
