Batteries
Electronic lock requires 4 AA Alkaline batteries (Duracell or Energizer recommended) to be purchased separately.
For best result, 1.2V Rechargeable batteries are NOT recommended. When all 4 batteries are installed in the correct
position, you will hear a long beep and the keypad will illuminate green.
Phillips Screwdriver
Drill Hole Saw Drill
Chisel Hammer
Tape Measure Pencil
Tools
Additional
Exterior Assembly Interior Assembly Latch Assembly Key x 2 Strike Plate
Parts
DO NOT mix new batteries with used batteries when the product is in use.
M4 Screws x 2
1-1/2” (40mm)
For door thickness
35 - 45mm
Strike Plate
Screws x 4
3/4” (19mm)
M4 Screws x 1
1/2” (12mm)
3
M4 Screws x 2
2-1/3” (60mm)
For door thickness
45mm or above
To Next Page
