Zip'r PC - Assembly Instructions; Figure 1: Component Overview; Figure 2: Seat Post Height Adjustment; Figure 3: Motor Release Levers

12
REQUIRED REQUIRED
Figure 1
Figure 2
Figure 3
ASSEMBLY
Figure 1
The Zip'r PC is comprised
of two main sections, the
operating unit and the vinyl
seat.
Figure 2
Adjust your seat post
support height by pulling
the metal pin, choosing the
appropriate height, and
reinserting the pin.
Figure 3
Twist the two motor release
levers such that they are
pointing outwards. This
position engages the motor
for operation. (Twist the
levers forward to release
the motor into freewheel
position as needed)
