Zip'r PC User Manual

13
REQUIRED REQUIRED
Figure 4
Figure 5
Figure 6
ASSEMBLY CONTINUED
Figure 4
Lift the seat onto the
chrome seat post support
by inserting the metal seat
post (attached under the
seat) into the chrome seat
post support. Test seat by
attempting to rotate – seat
should not be able to rotate
if installed correctly.
Figure 5
Install arm rests by
loosening arm rest set
knob located on the back of
the seat frame and then
inserting the arm rest into
the seat frame. Tighten the
arm rest set knob and
ensure that the set knob is
screwed fully through an
arm rest position hole.
Figure 6
After installing the arm
rests ensure that each arm
rest is securely in place.
After the arm rests are
securely installed you can
then locate and install the
joystick controller – see
figures 7, 8, and 9.

Zip'r PC Specifications

General

Brand	Zip'r
Model	PC
Category	Wheelchair
Language	English
