Zipro Jogger - Parts List

26
EN
PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
01 Main frame 1 29 Screw M8*15 3
02 L/R Left and right column 1 / 1 30 Screw ST4.2*12 12
03 Handrail 2 31 Endstop 69*42*42 2
04 Mobile device stand 1 32 Heart rate sensor 1
05
Front roller
1
33
Heart rate sensor
1
06 Rear roller 1 34 Console 1
07
Decal EVA 260*131*2.0
1
35
Safety key 950mm
1
08 Upper display cover 1 36 Motor 1
09
Running board t15*530*1155
1
37
Switch 250V/15A 13X28MM
1
10 Running belt t1.4*450*2570 1 38 Cable 1.8m 1
11
Belt drive 150
-
J5 54
1
39
Socket
1
12 Handrail plug 2 40 Wrench S6 80X80 1
13 Lower display cover 1 41 Supply cable 1.25mm2*270 10/15A 250 2
14 Handrail cover 2 42 Ground 1.25mm2*300 10/15A 250 1
15 L/R Left and right column cover 2 43 Bolt M8*50 S6 3
16 Upper motor cover 1 44 Screw ST4.2*16 10
17 Lower motor cover 1 45 Screw ST4.0*30 2
18 Inner left column cover 1 46 Screw ST4.2*16 17
19 Left column cover 1 47 Screw M8*25 S6 2
20 Inner right column cover 1 48 Screw ST4.2*16 12
21 Right column cover 1 49 Screw ST4.2*25 7
22
Column folding knob
2
50
Screw M6*35 S4
4
23 Lateral rail 82*65*1175 2 51 Screw M6*25 S4 4
24
Rear plug
1
52
Screw M8*40 s6
4
25 Guide wheel Φ45*Φ21*Φ8.5 4 53 Screw ST2.9*12 8
26
Stabilising feet Φ38*17*M6*30
2
54
Bolt M8*12 S6
2
27 Washer Φ25*30*M6*10 M6 4 55 Washer
∮
9*
∮
16*t1.5 2
28 Washer Φ30*Φ6*10 4 56 Spring washer D8 2
57 Washer
∮
5.2*
∮
10*t1 1 62 Foam adhesive 20*2.0*1115 4
58 Screw ST3.5*10 2 63 Left handrail cover 1
59 Anti-slip nut M8 S13 4 64 Right handrail cover 1
60 Flat washer
∮
10.5*
∮
20*t2.0 2 65 L/R Left and right column cover 1
61 Lower cable 1,800 mm 1
