Zipro Pacto - Parts List

27
EN
PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 31 Rubber damping washers 2
2 L/R Treadmill columns, left/right 1/1 32 Pulse sensor / Fast start-up
button Start/Stop
1
3 Computer frame 1 33 Pulse sensor / Fast speed change
buttons + / -
1
4 Support 1 34 Controller 1
5 Front roller 1 35 Safety wrench 950 mm 1
6 Rear roller 1 36 Motor 1
7 Spring 2 37 Power switch 1
8 Sleeve Φ18*8 2 38 AC adapter 1.8 m 1
9 Running board t15*530*1155 1 39 250 V socket 1
10
Running belt t1.4*450*2570
1 40 Overload protection 1
11 IGBT 130-J5 1 41 Single cable 250 V 270 mm 2
12 Upper computer cover 1 42 Earthing 250 V 300 mm 1
13 Lower computer cover 1 43 Bolt M8*50 3
14 Rail foam cover left 1 44 Screw 4.2*16 28
15 Rail foam cover right 1 45 Screw 4.0*30 4
16 Upper motor cover 1 46 Screw 4.2*16 17
17 Lower motor cover 1 47 Screw M8*25 2
18 Internal cover of left treadmill
column
1 48 Screw 4.2*16 12
19 External cover of left treadmill
column
1 49 Screw 4.2*25 7
20 Internal cover of right treadmill
column
1 50 Screw M6*35 4
21 External cover of right treadmill
column
1 51 Screw M6*25 4
22 Treadmill column knob 2 52 Screw M8*40 4
23 Side rail 2 53 Screw M6*35 2
24 End cover 1 54 Bolt M8*12 2
25 Handling wheel 4 55 Washer Φ9* Φ16*t1.5 4
26 Foot washer 2 56 Washer D8 4
27 Damper 1 4 57 Washer Φ5.2* Φ10*t1 1
28 Damper 2 2 58 Screw 3.5*10 1
29 “C” cap 2 59 Nut M6 S10 2
30 Computer cover knob 2 60 Washer Φ10.5* Φ20*t2.00 2
