Battery charger NG1
D01273-00 7
Mechanical dimensions
N.B. All dimensions are expressed in mm.
Drilling details
UP
Advised Installation
N.B. All dimensions are expressed in mm.
275
300
9
= =
155
==
16
80
Ø6
3
160
78
245
300
