Zivan NG1 - Technical Features; Mains Side Specifications; Battery Side Specifications

Battery charger NG1
D01273-00 8
TECHNICAL FEATURES
Ta=25°C unless otherwise specified
Mains side
Description Symbol Test Condition Value and/or
Range
Unit
Supply Voltage Vin - 230 ± 10% Veff
Frequency f - 50 ÷ 60 Hz
Absorbed Maximum Current Iin
max
P = P
max
6,8 Aeff
Inrush Current - Vin = 230Veff < 2,7 A
Power Factor
cosϕ
P = P
max
0,68 -
Absorbed Minimum Power Pin
min
End of charge < 5 W
Absorbed Maximum Power Pin
max
P = P
max
1 kW
Battery side
Description Symbol Test Condition Value and/or
Range
Unit
Output current I - See curve -
Maximum output current I1 Phase 1 See curve A
Output current ripple - I = I1 < 5% -
Absorbed current I
a
Equipment turned off < 0.2 mA
Output voltage U - See curve -
Constant output voltage U1 Phase 2 See curve V
Thermal compensation of output
voltage
dU1/dT Phase 2 -5
mV /
(°C·cell)
Operating range of Temperature
Sensor
∆T
- from -20 to +50 °C
Output voltage ripple - U = U1 < 1% -
Maximum power supplied P
max
U = U1, I = I1 864 W
Output capacity C -
Depend on the
model (>0,3)
mF
