Zivan SBM - Technical Features

English BATTERY DISCHARGER at constant current
22 D01470-03
Technical features
Feeding terminals
• Input voltage: 230 VAC
• Input frequency: 50-60 Hz
• Absorbed power: 150W
• Input fuse: 0,8A
Battery terminals
• Minimum working voltage: 3V
• Minimum working current: 1A (2A for the model with two units)
• Tolerance of reading value: ± 1,5%
General
• Ventilation: forced
• Working frequency: 20kHz
• Sizes (one unit): 465×265×400 mm
• Weight (one unit): 26kg
Protections and safety
• Inward self diagnostic check
• Thermal protection
• Inverse polarity protection
• Over voltage protection
Operating area (single unit)
1
10
100
1000
1 10 100 1000
Battery Voltage (V)
Discharge Current (A)
80-150
120-100
160-75
150
75
