Connection to ZKBioAccess Software
Here the connection between C2-260/inBio2-260 and AUX485 is used as an example to illustrate the
software settings. After proper wiring, perform the following steps:
1. Set the RS485 address of AUX485 from 1-15.
2. Inclusion of C2-260/inBio2-260 to software:
Open the ZKBioAccess Software. Click [Access] > [Device] > [Device] > [New], enter the relevant
information, and then click [OK].
Step 1
Step 2
Step3
Step 4
After adding successfully, the TCP/IP indicator of inBio2-260 ashes every two seconds, indicating the
communication is normal.
3. Inclusion of AUX485 module to the software:
Click [Device] > [I/O Board] > [New], enter the name and RS485 address of AUX485, and then click [OK].
11
