ZKTeco Horus User Manual

Side
2
Fingerprint & RFID (Optional)
Note:
1. The port on the back is used to DM10(RS485) and TCP/IP connection;
2. Not all the devices have the function with , the real product prevails.
Fingerprint Sensor &
ID/MF Card read area
Front
TCP/IP and RS485
extend port
(Horus E1-RFID, Horus
E1-FP has the port)
Rear
GND
485+
485-
TX+
TX-
RX+
RX-
RS485
Ethernet
Port Connection
Bottom
Bottom
Reset Button
Type C power-
interface

ZKTeco Horus Specifications

General

Brand	ZKTeco
Model	Horus
Category	IP Access Controllers
Language	English
