installation instructions
COOKTOP DIMENSIONS
A. WIDTH B. DEPTH C. HEIGHT
30” 21 ” 2 ¹/₈”
* DO NOT obstruct these areas
IMPORTANT: For proper ventilation, provide a vent under the countertop, in front of
the cabinet and in the back of the cabinet. The ventilation opening is to extend the full
length of the cooktop cutout.
Junction box approximate location: minimum 4 ¹/₂” below the cooktop.
