2.3 Hydraulic connecons
1: pump
2: lter
3: heang system
4: water treatment system
Respect the hydraulic connecon direcon (see $ "Dimensions" in the appendix).
Pipes
Maximum sucon rate at
1.8 metres/second
Maximum discharge rate at
2.4 metres/second
Ø50 mm 14 m³/h 19 m³/h
Ø 63 mm 20 m³/h 27 m³/h
• Choose the dimension of the pipes according to the size of the pool and respecng the hydraulic rules which apply in
the installaon country.
• Performance curves are available in the appendix for the pipe dimensions.
• The use of sucon and discharge union couplings is recommended to facilitate operaons on the equipment (the pump
intake and output are threaded by 2" on the interior).
• If there need to be more than 10 elbow joints on the hydraulic circuit, increase the pipe diameter.
• Avoid high points to simplify priming.
• Check that the hydraulic correcons are correctly ghtened and that there are no leaks.
• The pipes must be supported to prevent any risk of breakage due to the weight of water.
2.4 Electric connecons
• Risk of electric shock inside the equipment may cause serious injury or even death. Only a qualied and
experienced technician is authorised to carry out cabling in the equipment.
• The equipment must be connected to an earth socket.
• Any unsuitable electrical connecon will invalidate the warranty.
• Incorrectly ghtened terminals may cause the terminal unit to heat up and invalidate the warranty.
• If the supply cable is damaged, it must be replaced by a qualied technician.
2.4.1 Voltage and protecon
• Electrical protecon: by circuit breaker (D curve), with a 30 mA dedicated dierenal circuit breaker (circuit breaker or
switch) at the head of the line.
• The equipment and the swimming pool and any other electrical equipment must be connected to the Earth.
Acceptable variaon in voltage: +/-10% (during operaon).
2.4.2 Power supply and clock
Connect the pump to the 230 Vac relay downstream of the swimming pool electrical cabinet's ltraon clock.
The ltraon unit clock directly controls the pump's electricity supply, which then starts with the selected speed.
