DESCRIPTION - Functional Elements
MARK DESIGNATION
1 Bow roller
2 Bow ring
3 Anchoring rope locker cover
4 Fuel filling point
5 Tank vent
6 Fuel overflow drainage
7 Tank valve/gauge access hatch
8 Rear chest access hatch
9 Quick drain hole plug
10 Fuel/water separator filter
11 Engine cable feedthrough
12 Cleats
13 Quick drain hole
14 Hull plug hole
15 Rear chain plates
16 Engine trough access hatch
17 Battery tank
18 Tank hatch
19 Tank
20 Buoyancy mechanism
21 Mooring cleat
22 bolt ropes
23 handles
