6 | Vetscan Hub User’s Manual
System Overview
Powering On/Powering Off
The Vetscan Hub can be powered on by pressing the power button on the top of the Vetscan Hub.
The screen will then illuminate.
The Vetscan Hub can be powered o by pressing the power button on the top of the Vetscan Hub and holding it
for 5 seconds.
The Vetscan Hub is designed to be left on at all times, except when it will not be used for long periods (i.e.,
troubleshooting or repair).
If the device will not be used for long periods of time, turn o and unplug from its power source.
Touch Screen
The operator interacts with the Vetscan Hub through a touch screen. Ensure that the protective film is removed
from the touch screen prior to use.
Power Button
12V DV
Power connector
LAN Camera 2x USB 2.0
3x USB 3.0
Speaker
Standard VESA Mount
to Hub Stand
Speaker
USB Type C
Display Port
