ENGAGE AND BYPASS VIA MIDI
You can engage and bypass ZOIA by sending a Control
Change #60 to either 127 (engage) or 0 (bypass) on the
selected MIDI channel.
CONTROL PORT
The control port jack allows the ZOIA to be controlled by a
multitude of devices. Note that the ZOIA can only be connected
to one such device at a time, and the device must be selected
in the Cong Menu.
MIDI
The ZOIA Control Port can receive MIDI messages on the tip
of a ¼” TRS connector and send MIDI messages on the ring
of a ¼” TRS connector. Note that when the MIDI ports are in
use, the Control Port will only be able to send MIDI out, and
not accept MIDI in. Be sure to use a TRS connector instead of
a standard TS patch cable if you wish to send MIDI messages
from the Control Port.
EXPRESSION PEDAL (EXP)
The ZOIA is compatible with expression pedals that output
signal on the tip. You can enable expression pedal functionality
into your page using the module “cport exp/cv in” under the
“interface modules” list. You can then connect this module
to various buttons of other modules including audio eects
parameters, oscillator frequencies, VCAs etc. Have fun!
