Zoom A1X FOUR Quick Guide

5
Connecting a mic
Using the MAA-1, the
can be enjoyed with instruments that do not
have pickups, including harmonicas, violins, trumpets, saxophones and other string
and brass instruments.
1.
Open the battery compartment
cover on the back of the MAA-1 and
insert 2 AA batteries.
2.
Connect the mic to the MAA-1.
3.
Connect the MAA-1 to the
INPUT jack.
4.
Turn the MAA-1 power on.
• Set
to the ON position.
will light red.
When connecting a condenser mic or
other device that requires phantom
power, set it to the +48V position.
5.
Adjust the MAA-1 input level.
• Turn
.
Adjust so that lights green.
If the input level is too high,
will light red.
When connecting devices that are not compatible with phantom power, do
not set
to +48V. Doing so could damage the device.
NOTE
4
5
2
3
MAA-1

Zoom A1X FOUR Specifications

General

Number of Simultaneous Effects	5
Looper	30 seconds
Weight	610 g (without batteries)
Sampling Frequency	44.1 kHz
A/D Conversion	24-bit
D/A Conversion	24-bit
Display	LCD
Type	Multi-effects processor
Drum Machine	Yes
Patches	50
Rhythm Patterns	68
Output	1/4'' stereo output
USB	USB 2.0
Power	4 AA batteries, AC adapter (optional)
Frequency Response	20 Hz - 20 kHz +1 dB, -3 dB (10 kΩ load)
Input	1 x 1/4" (guitar), 1 x 1/8" (aux)
Effects	Guitar, bass, acoustic guitar
