Zoom B1 FOUR User Manual

Changing tuner settings
1.
Press when the TUNER screen is open.
This opens the TUNER setting.
Setting the output method
1.
Turn .
Setting Explanation
BYPASS Effects are bypassed and the bass sound is output.
MUTE The bass sound is not output.
HINT
You can also turn on the TUNER screen to change this setting.
Adjusting the standard pitch
1.
Turn .
HINT
• This sets middle A between 435 and 445 Hz.
• You can also turn on the Tuner Screen to change this setting.
41

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
