Zoom B1 FOUR User Manual

Setting the tuner type
1.
Turn .
Setting Explanation
CHROMATIC
The pitch detuning is shown according to the nearest note (in
semitones).
BASS
The nearest string number is shown according to the selected
type, and the amount of detuning from its pitch is shown. The
following tuner types can be selected.
Display
String number/note
LB 4 3 2 1 HC
BASS B E A D G C
HINT
• ”LB” is the low B string and ”HC” is the high C string.
Using at tunings
1.
Turn .
All strings can be tuned at from an ordinary tuning by one (
×1), 2 ( ×2) or 3 ( ×3) semitones.
NOTE
Flat tuning cannot be used when the tuner type is “CHROMATIC”.
42

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
