Zoom B1X FOUR User Manual

7
Using the tuner
Use this to tune the connected bass.
1.
Activate the tuner.
• Press
and at the same
time.
To close the tuner, press or
.
2.
Tune the bass.
• Play the open string that you want to
tune and adjust its pitch.
The nearest note name/string number and
pitch detuning will be shown on the screen
and by the LEDs.
When the pitch is accurate, the LED at the
center of the meter will light green and the
LEDs to the left and right will light red.
Setting the tuner
• Turn
and to set whether the bass sound is
output while tuning (BYPASS/MUTE) and the standard
pitch.
• Press
to open the TUNER SETTING screen
where you can set the tuner type and drop tunings.
Flat In tune Sharp
1
2
Pitch detuning
Nearest note name/string number
Bass sound
output
Standard
pitch

Zoom B1X FOUR Specifications

General

Simultaneous Effects	5
Expression Pedal	Yes
Looper	30 Seconds
Patches	50
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4"
Power Source	4 x AA batteries
