4
Making connections
█
Connecting mics and instruments
Dynamic mic
Condenser mic
Synthesizer
Synthesizer
Connect synthesizers, samplers,
effects and similar equipment to
channels 3 – 6.
Connect dynamic and condenser mics using the
XLR plugs.
Use cables and adapters so
line level devices connect to
the TRS plugs on the L6.
• When connecting condenser mics, press to supply phantom power.
• Do not supply phantom power to devices that are not compatible with it. Doing so could damage the device.
