zortrax M200 Replacement

The extruder bearing supports extrusion by pressing the material to the extruder
motor sprocket wheel during loading and the printing process. Therefore, when
the material in your printer is not being extruded when loading or printing, or the
sprocket wheel is making clicking sounds, the extruder bearing may be faulty and
should be replaced. Follow the steps from this manual to see the correct
replacement procedure.
If the material is loaded into the extruder, unload the material using the “Material” ->
“Unload material” option in the printer menu.
The following manual shows the M200 repair work. For the M300, these procedures are
the same.
page 3 / 24

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
