zortrax M200 Replacement

Table Of Content
Unplugging the Power Cable 4
Material Guide Removal 5
Unplugging the Extruder Cable 6
Unplugging all Cables from the Extruder PCB 7
Unscrewing the Extruder PCB 8
Extruder Lower Printed Cover Removal 9
Unscrewing the Extruder Aluminum Cover 10
Unscrewing the Extruder Motor 11
Extruder Motor Removal 12
Unscrewing the Extruder Bearing 13
Extruder Bearing Removal 14
Extruder Bearing Assembly 15
Extruder Motor Assembly, part 1 16
Extruder Motor Assembly, part 2 17
Extruder Aluminum Cover Assembly 18
Extruder Lower Printed Cover Assembly 19
Extruder PCB Assembly 20
Plugging all Cables into the Extruder PCB 21
Plugging the Extruder Cable 22
Material Guide Installation 23
Plugging the Power Cable 24
page 2 / 24

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
