zortrax M200 Quick Start Guide

1. Zortrax M200 should be turned off. Insert the Build Platform and
fit magnets (Pic. 1). Make sure that nozzle is clean. Connect two
connectors to the Build Platform carefully.
2. Tighten the screws (Pic. 3 - No. 1,2,3).
3. Manually move extruder to the A position (Pic. 4). Place a sheet
of paper with a thickness of a business card on the Build Platform
under the extruder.
4. Rotate Z Axis screw until nozzle will gently touch your object.
Note that during the following steps platform should not be
moved.
5. Slowly move extruder to the B position (Pic. 4). Set the distance
equal to the thickness of a business card using screw No. 2 (Pic.
3, near extruder).
6. Repeat it for C position (Pic. 4) and screw No. 3 (Pic. 3, near
extruder).
7. Then repeat it again for D position and screw No. 1.
8. Carefully move extruder back to the A position and check the
distance.
9. If you were able to level the platform you can start printing. If not,
please repeat all the steps.
CLEANING THE PLATFORM
17

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
