zortrax M200 Quick Start Guide

While printing, remains of the material may get stuck below printing
platform. After a certain time it may affect accuracy of the machine.
We recommend to follow these instructions ever few prints.
1. Please put gloves on. Unplug power cord and disconnect the
cables from the Build Platform. Remove it carefully.
2. Using hex key remove 9 screws connecting perforated plate to
the aluminum plate.
3. Carefully clean perforated plate from both sides using spatula.
A. It is not necessary to remove rest of the material from perfora-
tions – it will not affect the printing process.
B. After cleaning, wipe the top of the perforated plate with acetone,
if necessary. Do it carefully.
C. Make sure that aluminum plate is clean and place perforated
plate on it.
D. Connect both plates together.
16
CLEANING THE PLATFORM

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
