ZOTAC ZBOX nano
6. Turning on the system
Connect the supplied AC adapter to the DC IN jack on the system rear panel and
then press the power switch on the front panel to turn on the system.
7. Connecting to an HDMI display
Connect one end of an HDMI cable to the HDMI port on the system rear panel
and the other end to a HDMI-compatible display such as an HDTV or monitor.
(When both the HDMI and the DP are connected, the audio output is from HDMI
by default.)
8. Connecting to a home network
Connect one end of a network cable to the LAN port on the system rear panel and
the other end to a network hub, switch or router.
9. Connecting an eSATA device
Connect one end of an eSATA device to the eSATA port.
Note: When your ZOTAC ZBOX nano is not in use, unplug the power adapter or switch off the AC outlet
to conserve power.
6
7
8
9
