PAGE 2 OF 4
ZURN INDUSTRIES, LLC 5900 Elwin Buchanan Drive, Sanford, NC U.S.A. 27330, Ph. 1-800-997-3876, Fax 919-775-3541
In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292
Rev. C Date: 6/25/2018 C.N. No. SAN008311 Prod. | Dwg. No. CF1193
MAINTENANCE
1. YOUR ZURN AQUASPEC FAUCET HAS A HIGHLY POLISHED NICKEL CHROME PLATED FINISH. CLEAN WITH SOAP
AND WATER OR A MILD CLEANER WHICH IS SAFE FOR CHROME PLATING. DO NOT USE ACIDS OR TOILET BOWL
CLEANER AS THEY WILL DAMAGE THE FINISH.
2. METERING CARTRIDGE (#3) REMOVAL AND REPLACEMENT.
2.1. REMOVE COLORED INDEX BUTTON (#1D) FROM HANDLES (#1A + #1B).
2.2. LOOSEN SET SCREWS (#1C) IN HANDLE WITH 3/32” ALLEN WRENCH.
2.3. PULL UP ON HANDLE TO REMOVE FROM STEM (#2B) OF HANDLE NUT ASSEMBLY (#2).
2.4. REMOVE HANDLE NUT ASSEMBLY (#2) USING 1-1/8” HEX 6-POINT SOCKET.
2.5. REMOVE METERING CARTRIDGE (#3) BY LIFTING OUT OF FAUCET BODY (#5). IT MAY BE NECESSARY TO
OPEN THE SUPPLY STOP SLIGHTLY TO ALLOW WATER PRESSURE TO PUSH THE METERING CARTRIDGE UP-
WARD.
2.6 INSPECT METERING CARTRIDGE (#3) FOR WORN PARTS, DAMAGED PARTS AND ANY CONTAMINATION
THAT MAY BE PREVENTING THE METERING CARTRIDGE FROM MOVING FREELY OR SEATING. OTHER THAN
CLEANING ANY TRAPPED DEBRIS, THERE ARE NO SERVICEABLE PARTS IN THE METERING CARTRIDGE.
CONTAMINATED OR DAMAGED METERING CARTRIDGE ASSEMBLIES SHOULD BE REPLACED.
2.7 REVERSE STEPS 2.1 THROUGH 2.5 FOR RE-ASSEMBLY. TIGHTEN CAP (#2F) WITH 1-1/8” HEX 6-POINT SOCKET
UNTIL NO WATER IS LEAKING FROM UNDER THE HANDLE NUT ASSEMBLY WHEN THE FAUCET IS RUNNING.
HOLD DOWN HANDLES (#1A + #1B) WHILE TIGHTENING SET SCREW (#1C) TO ENSURE PROPER SEATING.
3. IT MAY BE NECESSARY TO REPLACE OR BACK FLUSH THE INTEGRAL SHANK FILTER (#4) AND AERATOR (#6) PERI-
ODICALLY TO REMOVE COLLECTED SEDIMENT AND DEBRIS.
3.1. INTEGRAL SHANK FILTER(#4) IS REMOVED USING A 1/4” ALLEN WRENCH.
REPLACEMENT PARTS
HANDLE NUT ASSEMBLY G60561
METERING CARTRIDGE ASSEMBLY G61754
HANDLE ASSEMBLY G61830
INTEGRAL SHANK FILTER G68020
ADJUSTING THE CYCLE TIME ON ZURN METERING FAUCET
1. METERING FAUCETS ARE FACTORY PRESET FOR A 10 TO 15 SEC. CYCLE AT 80 PSI.
2. ACTUATE FAUCET 3 TO 5 TIMES TO REMOVE ANY TRAPPED AIR IN THE SUPPLY LINE OR FAUCET
3. REMOVE HANDLE (#1) PER INSTRUCTIONS IN MAINTENANCE SECTION 2.1 THROUGH 2.3 TO EXPOSE ADJUSTMENT
NUT (#2E)
4. INCREASE CYCLE TIME BY TIGHTENING ADJUSTMENT NUT (#2E) 1/2 TURN CLOCKWISE. DECREASE CYCLE TIME BY
LOOSENING ADJUSTMENT NUT 1/2 TURN COUNTERCLOCKWISE. CHECK FOR DESIRED CYCLE TIME BY ACTUATING
FAUCET WITH HANDLE (#1) IN PLACE ON STEM (#2B)
Installation Instructions are revised frequently.
Please access website for the latest revision.
*
