2.2 Mechanical Installation
2N Access Unit M is designed for surface mounting (wall, plasterboard, door frames).
Use the drilling template shown on the device box to prepare holes of the required
sizes for cabling and dowels on the selected place in the required height. Feed the
cables out of the pre-predrilled hole.
Loosen the screws to unscrew the holder from the device backside and slide the
holder downwards.
