Legend
Tamper
Switch
A switch that helps detect the removal of a device from the holder installed.
RESET
button
RESET / FACTORY RESET button.
All the available cables are 35 cm long.
Wiring diagram for Relay cables
The electric lock is unlocked whenever power is supplied
The magnetic lock is unlocked whenever the power supply is
disconnected
