3.1 Programming
All the intercom parameters, including the keypad ones, are set remotely using any
tone-dialling telephone set (or a mobile phone). First call the intercom and enter the
programming mode. The access to this mode is service password protected.
A voice menu is available in the programming mode and so you need not use this
manual to program standard parameters. The menu is stored in the intercom memory
in the default language. Having entered the full parameter or memory number, you
can hear how the parameter has been programmed, thus checking the programmed
numbers for correctness.
All parameters are stored safely in the non-volatile EEPROM memory.
Tip
Write or print the values to be programmed to minimise the risk of error.
Moreover, this gives you an idea of what you have programmed. Make
sure that programming is not barred (JP1 jumper) – refer to the PCB
Description subsection.
Entering Programming Mode
You can enter the programming mode only during an call (telephone – incoming
intercom call). The programming barring jumper must not be mounted. To get into the
programming mode, enter the in the formatservice password
(do not forget to enter the asterisks before and behind the password
password!). The service password is 12345 by default and can be changed. If you enter
the password correctly, the voice menu is launched. Now you can start programming.
Programming Procedure
You can set parameters in any order and as many times as you wish. To change a
parameter use the following command:
Parameter number parameter value
A three-digit is assigned to every parameter to be programmed parameter number
and to every memory (refer to the Programming Chart). This number indicates to the
intercom which parameter to change, and is used as "Enter". When it is entered,
the intercom repeats the parameter (or memory) number and reads the current
