2N Helios IP Instruction Manual

11
www.yonnet.com.tr
2N
®
Helios
Static & DHC IP Settings
2.3
2.3
Over DeviceStaticand DHCP IP settings
• For static IP to;
StandardIP:192.168.1.100 ıt is set.
• 2N Helios’ power connection is made.
• Work is expected that the first warning tone.
• According to the model applied the following button combination.
• 1 for push-button models;
• 15 times within 30 seconds of the single button needs to be pressed.
• 3-button models for;
• 1, 1, 1, 2, 2, 3 button must be pressed to include in 30 seconds.
• 6-button models for;
• 4, 4, 4, 5, 5, 6 button must be pressed to include in 30 seconds.

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
