2N Helios - 2.6 Buttons Labels - Insertion, Replacement

37
2.6 Buttons Labels – Insertion,
Replacement
Instructions
1. Remove the 2N® Helios metal cover. To do this,
use a hexagonal key, unscrew the screw as
shown in the figure and take the cover off.
2. Remove the name plates as shown in the
figure using, e.g., a screw driver.
3. Remove the name plate inserts as shown
in the figure.
4. Insert the labels printed on foil (see later).
5. Replace the name plate inserts.
6. Put the name plates back in the depression and click into position. The name
plates keep the matt foil steady.
7. Replace and screw on the metal cover.
Note
 You can remove the name plates even without removing the metal cover
however damage, if any, incurred as result of this, is not covered by the
warranty.
