Table 1-3 Technical specifications of the Switch.
Specification 2816 2824
Physical
dimensions
(H×W×D)
44 mm×440
mm×173 mm
(1.73 × 17.32 ×
6.81 in.)
44 mm×440
mm×173 mm
(1.73 × 17.32
× 6.81 in.)
Weight
<1.65 kg(3.64
lb)
<1.75 kg(3.86
lb)
Ethernet port
quantity
16 24
Physical
Mounting
Free standing, or 19-inch rack
mounted using the mounting kit
supplied
Power Inlet IEC 320
AC Input
Voltage
Rating
Rated voltage range: 100-240V
AC, 50/60 Hz
Current
Rating
1Amp max
Electrical
Maximum
Power
Consumption
15W 20W
Operating
temperature
0°C to 40°C (32°F to 104°F)
Storage
temperature
–40°C to +70°C (–40°F to 158°F)
Operating
humidity
5% to 95% (noncondensing)
Environmenta
l
Storage
humidity
5% to 95% (noncondensing)
