Ethernet Port RJ-45 Pin Assignments 57
Tab l e 11 Pin assignments
Pin Number 10/100 1000
Ports configured as MDIX
1 Receive Data + Bidirectional Data B+
2 Receive Data − Bidirectional Data B−
3 Transmit Data + Bidirectional Data A+
4 Not assigned Bidirectional Data A−
5 Not assigned Bidirectional Data D+
6 Transmit Data − Bidirectional Data D−
7 Not assigned Bidirectional Data C+
8 Not assigned Bidirectional Data C−
