1-4
3Com Baseline Switch 2928-SFP Plus
Front Panel
Figure 1-3 3Com Baseline Switch 2928-SFP Plus front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) Port status LED
(3) Power LED (Power) (4) Console port
(5) 1000Base-X SFP interface
Rear Panel
Figure 1-4 3Com Baseline Switch 2928-SFP Plus rear panel
(1) AC receptacle (2) Grounding screw
Power Supply System
AC power input:
Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Input voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz
Cooling System
The 3Com Baseline Switch 2928-SFP Plus is equipped with one fan for heat dissipation.
