Router 3016 and Router 3018 17
AUX Port
Table 19 lists attributes of the AUX port.
Ethernet Port
Table 20 lists attributes of the Ethernet port.
CT1/PRI and E1/CE1/PRI Ports
Table 21 lists attributes of the CT1/PRI and and E1/CE1/PRI ports.
Baud rate 9.6 to 115.2 kbps (the default is 9.6 kbps)
Services Connects with character terminal
Connects with serial ports of the local PCs and runs the terminal
emulation program on the PCs
Command line interface
Tab le 19 Attributes of the AUX Port
Attribute Description
Connector RJ-45
Port standard Asynchronous EIA/TIA-232
Baud rate 300 bps to 115.2 kbps
Services Modem dial-up
Backup
Protocols PPP (Point to Point Protocol)
SLIP (Serial Line Internet Protocol)
MP (Multilink PPP)
Tab le 20 Attributes of the Ethernet Port
Attribute Description
Connector RJ-45
Frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Operating mode 10/100 Mbps autosensing
Full duplex/half duplex
Network protocol IP (Internet Protocol)
Novell IPX (Internet Packet Exchange)
Tab le 21 Attributes of the CT1/PRI Port
Attribute CT1/PRI Description E1/CE1/PRI Description
Connector RJ-45 DB15
Port standard G.703/T1 102 and G.704
Port rate 1.544 Mbps 2.048 Mbps
Table 18 Attributes of the Console Port (continued)
Attribute Description
